K2 Evo 130

For light weight crews

A popular low volume club boat, purpose built with the smaller paddlers in mind

This low volume K2 model has a classic V-shaped hull with minimum rocker. To let the shorter ones paddle with comfort the boat has low deck height and narrow cockpits. The Evo E130 has truly stood the test of time and has remained a firm favourite model among many clubs for youth crews, usually between the ages of 13 - 16.

  • Crew weight

    120 - 140 kg

  • Length

    650 cm
  • Width

    37 cm
  • Stability level

    1/10
  • Boat weight

    18 kg
    (Marathon: 15.5 kg)
  • Cockpit sizes

    Front: 87 x 37 cm, Rear: 102 x 37 cm
  • 01

  • 02

  • 03

  • 04

  • 05

  • 07

  • 08

  • 09

Features & fittings

Seat

    All kayaks are equipped with low back racing seat with traditional design as standard - the most popular seat shape in the market.

    Alternatives are:

    • Low position seat reducing seat height by 1 cm giving more stability for the athlete,
    • High-back seat for athletes looking for a better grip on the back,
    • Rotofix seat aims to assist hip movement and giving a good grip & comfort at the same time,
    • Rotoseat is for training to improve hip and leg movement.

    All racing seat is fixed to the same platform rails installed in the kayak so they are convertible with each other.

    Footrest and foot strap

      Kayaks are equipped with simple yet reliable footrests with easy-to-adjust spring sliding system. The fixing frame & fittings of the footrest are positioned behind the footplate, so the full width of the boat is available for your feet. This provides comfort & full use of the tiller bar for effective steering. It is also perfect for club use to regularly adjust the footrest distance.

      Reaching under the footrest you can find two thumb nuts at the bottom of the fixing frame - they are to secure the footrest position. Don't forget to realease them before adjusting the footrest distance by the spring slider.

      The footplate is covered with EVA traction pad for non-slip and increased comfort, and equipped with adjustable foot strap.

      Narrow footrest with fixed angle footplate is equipped as standard but full footrest with adjustable angle footplate is available for maximum leg drive & customisation.

      However our spring sliding footrest system provides high adjustability, please let us know if the boat is for a much shorter or taller paddler (approx. under 170 cm or over 185 cm). Then the complete footrest system will be moved more forward or backward during the construction of the kayak. It may be also important for us to know if the boat is for 13-16 year old paddlers stil in growth spurt.

      Rudder

        The kayak is equipped with a high performance plastic race rudder as standard. It provivides excellent tracking with minimum drag and turbulance. These unbalanced & thin rudders have a low blade surface and 6 mm rudder shaft.

        Choosing a durable stainless rudder may be a good option for marathon paddlers or for summer trainings in still water. It is less prone to impact damages during portages or caused by woody debris, not to mention that it also minimises the unpleasant weed pick-up.

        Available bulkhead(s)

        NO bulkheads are installed in flat water racing kayaks as standard. However rear, front or both bulkheads can be installed on request if the boat will be used by paddlers under the age of 14-15, beginners or unstable paddlers.

        A bulkhead (partition) is an upright wall within boat separating watertight compartments so that the capsized boat does not sink. A hatch is placed in the rear bulkhead, mainly to let the rear compartment to dry when not in use and to ventilate the stored boat.

        CONSTRUCTIONS
        To let us meet the preferences of a wide range of paddlers we offer multiple constructions to choose from. These constructions are set up in line with the requirements of each segment of the flatwater racing market - from youth paddlers to top-ranking athletes, from local clubs to federations - while providing the most favourable quality and price conditions for that specific group of users.

        More about constructions

        Constructions differ in the materials and technologies used during the manufacturing process. These determine the stiffness and the interior appearance of the boat. In practice, an upper construction results a stiffer & more eye-catching boat.

        Besides, the standard and available fittings may be also different in some constructions. These are listed at the "Fittings" section of this article.


        • CLASSIC

          Basic constrution for CLUB USE


          Sandwich core material


          Vinyl ester resin


          Vacuum bagging (hull)


          Hand lay-up (deck)


          Stiffness

        • EXTRA

          Economy carbon constrution for SPRINT TRAINING


          Sandwich core material


          Carbon reinforcement
          (Clear carbon available)


          Vinyl ester resin


          Vacuum bagging


          Stiffness

        • ULTRA

          High performance carbon constrution for SPRINT RACING


          Foam core material


          Double carbon reinforcement
          (Clear carbon available)


          Epoxy-vinyl ester resin


          Vacuum bagging


          Stiffness

        • MARATHON

          Light weight carbon construction for MARATHON TRAINING & RACING


          Foam core material


          Light weight carbon reinforcement


          Epoxy-vinyl ester resin


          Vacuum bagging


          Stiffness


        Design & colour customisation

        All boats are made to order. You can choose your preferred colour(s) of the hull, the deck areas, the trim (seam between deck & hull), the cockpit rims (coamings) and the seats.

        These deck designs are available in all constructions:

        • #0000 - MONO
        • #0101 PARALLEL
        • #0201 - POINTED
        • #0301 - CHEVRON
        • #0302 - CHEVRON VAR
        • #0303 - CHEVRON DOUBLE
        • #0304 - CHEVRON WING
        • #0305 - CHEVRON WING VAR
        • #0306 - CHEVRON POINTED
        • #0401 - ZIG
        • #0402 - ZIG-ZAG
        • #0403 - ZIG-ZAG-ZAG-ZIG
        • #0404 - ZIG-ZIG-ZAG-ZAG
        • #0501 - NOSE-TAIL
        RAL 1001
        RAL 1001 "Beige"
        RAL 1016
        RAL 1016 "Sulfur yellow"
        RAL 1018
        RAL 1018 "Zinc yellow"
        RAL 1023
        RAL 1023 "Traffic yellow"
        RAL 2003
        RAL 2003 "Pastel orange"
        RAL 2004
        RAL 2004 "Pure orange"
        "KAPE red"
        RAL 3003
        RAL 3003 "Ruby red"
        RAL 3020
        RAL 3020 "Traffic red"
        RAL 3027
        RAL 3027 "Raspberry red"
        RAL 4003
        RAL 4003 "Heather violet"
        RAL 4004
        RAL 4004 "Claret violet"
        RAL 4005
        RAL 4005 "Blue lilac"
        RAL 4006
        RAL 4006 "Traffic purple"
        RAL 4008
        RAL 4008 "Signal violet"
        RAL 4010
        RAL 4010 "Telemagenta"
        RAL 5002
        RAL 5002 "Ultramarine blue"
        RAL 5003
        RAL 5003 "Sapphire blue"
        RAL 5005
        RAL 5005 "Signal blue"
        RAL 5010
        RAL 5010 "Gentian blue"
        RAL 5012
        RAL 5012 "Light blue
        RAL 5013
        RAL 5013 "Cobalt blue
        RAL 5015
        RAL 5015 "Sky blue
        RAL 5017
        RAL 5017 "Traffic blue
        RAL 5018
        RAL 5018 "Turquoise blue"
        RAL 5021
        RAL 5021 "Water blue"
        RAL 5023
        RAL 5023 "Distant blue"
        RAL 6001
        RAL 6001 "Emerald green"
        RAL 6018
        RAL 6018 "Yellow green"
        RAL 6019
        RAL 6019 "Pastel green"
        RAL 6026
        RAL 6026 "Opal green"
        RAL 6029
        RAL 6029 "Mint green"
        RAL 6034
        RAL 6034 "Pastel turquoise"
        RAL 7001
        RAL 7001 "Silver grey"
        RAL 7004
        RAL 7004 "Signal grey"
        RAL 7016
        RAL 7016 "Anthracite grey"
        RAL 7024
        RAL 7024 "Graphite grey"
        RAL 7033
        RAL 7033 "Cement grey"
        RAL 7037
        RAL 7037 "Dusty grey"
        RAL 7047
        RAL 7047 "Telegrey 4"
        RAL 9010
        RAL 9010 "Pure white"
        RAL 9017
        RAL 9017 "Traffic black"
        Clear carbon (limited availability)
        Clear carbon (limited availability)
        Clear carbon-kevlar (limited availability)
        Clear carbon-kevlar (limited availability)

        Tips & more about the available colours


        Think carefully about choosing black and dark colours!

        Such boats warm up more & they become matt very soon. Scratches and limescale are also much more visible on these surfaces.

        Less is more:

        We recommend picking only two, maximum three colours for a coherent boat design.

        More is more:

        (Because of the overlapping gelcoat layers) more colours results in more weight.


        Availability of clear (transparent) surfaces:

        Clear carbon seats & cockpit rims are available in EXTRA & ULTRA constructions.

        Clear carbon hull and/or deck (parts) are available in EXTRA & ULTRA constructions.
        (Bow & stern of the clear carbon boat are black gradient)

        Clear carbon-kevlar hull is available in SUPER construction.
        (Bow & stern of the clear carbon-kevlar boat hulls are colored)


        RAL colors CANNOT be displayed entirely proper on computer screens. The color depends on your monitor and printer. Therefore the exact shade of the product may be different than seen here! Please use these color samples as a reference only! We recommend you to see a physical and official RAL color guide to be sure of the correct color.

        FITTINGS
        • CLASSIC

          Standard Choice

          S111
          Racing Seat
          F111
          Full & Adjustable Angle Footrest
          FP1
          Velcro Foot Strap
          FT111
          Traction Pad for Footrest
          R112
          Racing Rudder
          M12
          Number Holder

          Available at no extra charge

          S112
          High Back Racing Seat
          R122
          Stainless Marathon Rudder

          Available for extra charge

          FP2
          Pull bar
          S113
          Rotoseat
          R123
          Stainless Overstern Rudder
          +R1X1
          Spare Part: Racing or Stainless Marathon Rudder
        • EXTRA

          Standard Choice

          S111
          Racing Seat
          F111
          Full & Adjustable Angle Footrest
          FP1
          Velcro Foot Strap
          FT111
          Traction Pad for Footrest
          R112
          Racing Rudder
          M12
          Number Holder

          Available at no extra charge

          S112
          High Back Racing Seat
          R122
          Stainless Marathon Rudder

          Available for extra charge

          FP2
          Pull bar
          S113
          Rotoseat
          R123
          Stainless Overstern Rudder
          +R1X1
          Spare Part: Racing or Stainless Marathon Rudder
        • ULTRA

          Standard Choice

          S111
          Racing Seat
          F111
          Full & Adjustable Angle Footrest
          FP1
          Velcro Foot Strap
          FT111
          Traction Pad for Footrest
          R112
          Racing Rudder
          M12
          Number Holder

          Available at no extra charge

          S112
          High Back Racing Seat
          FP2
          Pull bar
          R122
          Stainless Marathon Rudder

          Available for extra charge

          S113
          Rotoseat
          R123
          Stainless Overstern Rudder
          +R1X1
          Spare Part: Racing or Stainless Marathon Rudder
        • MARATHON

          Standard Choice

          S111
          Racing Seat
          F111
          Full & Adjustable Angle Footrest
          FP1
          Velcro Foot Strap
          FT111
          Traction Pad for Footrest
          R122
          Stainless Marathon Rudder
          M12
          Number Holder

          Available at no extra charge

          S112
          High Back Racing Seat
          FP2
          Pull bar
          R112
          Racing Rudder

          Available for extra charge

          S113
          Rotoseat
          R123
          Stainless Overstern Rudder
          +R1X1
          Spare Part: Racing or Stainless Marathon Rudder

        Find a dealer!

        Our distributor partners from all over the world are happy to help you to get your boat as soon as possible. Find your nearest KAPE dealer!
        If you cannot find a dealer in your country, please contact us directly using the form below!

        Contact us

        Should you need any further information, please do not hesitate to contact us directly. We are at your disposal for any clarification
